Processor and Memory Card Cover
The following procedures cover removal and replacement of the processor and memory
card cover.
Removal
1. If you have not already done so, shut down the system as described in “Stopping
the System” on page 254.
2. If your system is a Model 6C1 (rack mount), place the system in the service position
as described in “Placing the Model 6C1 in the Service Position” on page 255.
3. If you have not already done so, remove the service access cover as described in
“Covers” on page 258.
4. Record any memory card or processor LEDs that are on.
5. Pull out on the snap button, and remove the processor and memory card cover.
Snap
Button
Replacement
Replace in reverse order.
264 Service Guide
