Table 3. Firmware Error Codes. (continued)
Error Code Description Action / Possible Failing FRU
450000D2 System bus protocol/transfer error
(checkstop)
1. Replace the FRU as indicated by
the physical location code
displayed on the operator panel.
2. Check the service processor error
log for additional FRUs.
450000D3 I/O host bridge time-out error (checkstop) 1. Replace the FRU as indicated by
the physical location code
displayed on the operator panel.
2. Check the service processor error
log for additional FRUs.
450000D4 I/O host bridge address/data bus parity
error (checkstop)
1. Replace the FRU as indicated by
the physical location code
displayed on the operator panel.
2. Check the service processor error
log for additional FRUs.
450000D6 System support function error (checkstop) 1. Replace the FRU as indicated by
the physical location code
displayed on the operator panel.
2. Check the service processor error
log for additional FRUs.
450000D7 System bus internal hardware/switch
error (checkstop)
1. Replace the FRU as indicated by
the physical location code
displayed on the operator panel.
2. Check the service processor error
log for additional FRUs.
450000DA The processor was found deconfigured.
The service processor reconfigured the
available processor.
1. Note that this error code indicates
that the corresponding FRU has
been reconfigured. Check the
processor config/deconfig menu in
the service processor system
information menu before replacing
parts.
2. Replace the processor card.
Location: P1-C1
Location: P1-C2
450000DB All memory DIMM pairs were found
deconfigured. The service processor
reconfigured the best available pair.
1. Note that this error code indicates
that the corresponding FRU has
been reconfigured. Check the
processor config/deconfig menu in
the service processor system
information menu before replacing
parts.
2. Replace all memory DIMM pairs.
45800000 Memory controller checkstop Go to “MAP 1540: Minimum
Configuration” on page 63.
160 Service Guide
