Symptom Action
The power LEDs on the operator
panel and power supplies do not
start blinking within 30 seconds
of ac power application and the
operator panel display is blank.
Go to ″MAP 1520: Power″, “Step 1520-2” on page 55.
The power LEDs on the operator
panel and power supplies are
blinking and the operator panel
display is blank.
Go to ″MAP 1520: Power″, “Step 1520-3” on page 55
The power LED on the operator
panel is on solid, the power
LEDs on the power supplies are
blinking and the operator panel
display is blank.
When the power on switch on
the operator panel is pressed,
there is no indication of activity.
The power LED on the power
supply does not change from
blinking to solid and none of the
fans, including the fan in the
power supplies, start to turn.
Go to ″MAP 1520: Power″, “Step 1520-3” on page 55
The power LEDs on the operator
panel and power supplies are
blinking and OK, STBY or DIAG
STBY is displayed on the
operator panel display.
When the power on switch on
the operator panel is pressed,
there is no indication of activity.
None of the power LEDs change
from blinking to solid and none of
the fans, including the fan in the
power supplies, start to turn.
Go to ″MAP 1520: Power″, “Step 1520-3” on page 55
The power LEDs on the operator
panel and power supplies are
blinking and OK, STBY or DIAG
STBY is displayed on the
operator panel display.
When the power on switch on
the operator panel is pressed,
the power LEDs change from
blinking to solid and the system
begins to power on, but the
power LEDs on the operator
panel and power supplies do not
stay on and the system powers
off.
Go to ″MAP 1520: Power″, “Step 1520-3” on page 55
Chapter 3. Maintenance Analysis Procedures (MAPs)
39
