ICD NeoGCP i7 PLUS+ - Button Usage and LED Lighting Status; Button Usage; LED Lighting Status

REV. N
NeoGCP i7 PLUS+
- 10 -
2. Button usage and LED Lighting Status
Button usage 2.1.
- Adjustment and setup of various operation information possible with buttons on the front.
ITEM
DESCRIPTION
DIRECTION
BUTTON
- Use to select generator information on Main screen.
- Use to move Menu on Menu screen.
- Use to move digits or change information on Menu screen.
MODE
- Use to switch to [BLOCK], [MANUAL], [AUTO] mode.
MENU
- Use to switch from Main screen to Menu screen.
ENTER
- Use to select menu from Menu screen.
- Use to input generator information on Menu screen.
ESC
- Use to switch from Menu screen to Main screen.
- Use to cancel changes of generator information on Menu screen.
- Use to switch from Alarm check screen to Main screen without release
of Alarm.
LAMP TEST
- Use to check LED on Main screen.
ALARM
- Use to switch to Alarm check screen when Alarm occurs.
- Use to check Alarms in a sequential order when many Alarms occur.
RESET
- Use to release Alarm
CLOSE
- Use to close breaker in [MANUAL] mode.
OPEN
- Use to open breaker in [MANUAL] mode.
START
- Use to start generator in [MANUAL] mode.
STOP
- Use to stop generator in [MANUAL] mode.
LED Lighting Status 2.2.
- LED indicates status of various operation and faults, whether breaker is open or closed.
ITEM
COLOR
DESCRIPTION
BLOCK
Yellow
Lit in [BLOCK] mode
MANUAL
Yellow
Lit in [MANUAL] mode
AUTO
Yellow
Lit in [AUTO] mode
GRID ON
Red
Lit in Mains On, off in Mains Off
ALARM
Red
Lit in Alarm condition, off when Alarm is released
CLOSE
Red
Lit in [BREAKER CLOSE], Off in [BREAKER OPEN]
OPEN
Green
Lit in [BREAKER OPEN], Off in [BREAKER CLOSE]
START
Yellow
Off in [STOP]
