NeoGCP i7 PLUS+
- 50 -
13. SERIAL COMM
- NeoGCP i7 has 2 comm ports.
- Setup of D-SUB 9pin is fixed as UART communication port.
Items
Description
Setup
UART ID
ID
Setup device ID for UART port
002
UART BAUD
RATE
BAUD
Setup Baud Rate for UART port
9600
UART PARITY
PARITY
Setup Parity for UART port
EVEN
- RS485 ± setup through port number [12],[13] are as shown below.
Items
Description
Setup
RS485 ID
ID
Setup device ID for RS485
0 ~ 255
RS485 BAUD
RATE
BAUD
Setup Baud rate for RS485 port
9600, 19200, 38400
RS485 PARITY
PARITY
Setup Parity for RS485 port
NONE, EVEN, ODD
RS485
PROTOCOL
PROTOCOL
Setup RS485 protocol
MODBUS, GIMAC-II
Plus
RS485 WORD
SWAP
SWAP
If RS485 protocol is GIMAC-II Plus,
select WORD SWAP use/not use
Use, Not use
14. GAIN-SET
- If actual voltage and current values are different from displayed voltage and current values, change of
value is possible by changing Gain setup.
Items
Description
Setup
PT U-V GAIN
PT-UV
Gain for Gen U-V Voltage
0.001 ~ 9.999
PT V-W GAIN
PT-VW
Gain for Gen V-W Voltage
0.001 ~ 9.999
PT W-U GAIN
PT-WU
Gain for Gen W-U Voltage
0.001 ~ 9.999
CT U GAIN
CT-U
Gain for Gen U Current
0.001 ~ 9.999
CT V GAIN
CT-V
Gain for Gen V Current
0.001 ~ 9.999
CT W GAIN
CT-W
Gain for Gen W Current
0.001 ~ 9.999
CT GR GAIN
CT-GR
Gain for Gen Ground Current
0.001 ~ 9.999
MAIN R-S GAIN
MAIN-RS
Gain for Main R-S Voltage
0.001 ~ 9.999
MAIN S-T GAIN
MAIN-ST
Gain for Main S-T Voltage
0.001 ~ 9.999
BAT VOLT GAIN
BAT-V
Gain for Battery Voltage
0.001 ~ 9.999
CT U OFFSET
CT-U
Offset for Gen U Current
0 ~ 100
CT V OFFSET
CT-V
Offset for Gen V Current
0 ~ 100
CT W OFFSET
CT-W
Offset for Gen W Current
0 ~ 100
CT GR OFFSET
CT-GR
Offset for Gen GR Current
0 ~ 100
