ICD NeoGCP i7 PLUS+ - GIMAC-II Plus PROTOCOL

REV. N
NeoGCP i7 PLUS+
- 61 -
GIMAC-II Plus PROTOCOL 18.2.
Items
Setup
Protocol Type
MODBUS RTU
Communication Configuration
RS485 Half Duplex
Device ID Setup
0 ~ 255
Baud Rate Setup
9600, 19200, 38400 [bps]
Parity Setup
Even, Odd, None
Data Bit
8 [bit]
Stop Bit
1 [bit]
Support Function Code
Request(04h) only
Support Exception Code
Illegal Function(01h), Illegal Address(02h), Illegal Data
Value(03h)
Frame-End Silent Interval
Firmware under V2.66 : 50[ms], Firmware over V2.67 : 5[ms]
Support Address
30001 ~ 30035
REQUEST (04h) 18.2.1.
ADDRESS
DATA
TYPE
SCALE
01
DI status
16Bit UNSIGNED INT
Note6)
02
DO status
16Bit UNSIGNED INT
Note6)
03
Device status
16Bit UNSIGNED INT
Note6)
04
Reserved
16Bit UNSIGNED INT
05
Gen U current [A]
32Bit FLOAT
07
Gen V current [A]
32Bit FLOAT
09
Gen W current [A]
32Bit FLOAT
11
Gen U-N voltage [V] (Phase voltage)
32Bit FLOAT
13
Gen V-N voltage [V] (Phase voltage)
32Bit FLOAT
15
Gen W-N voltage [V] (Phase voltage)
32Bit FLOAT
17
Gen U-V voltage [V] (Line voltage)
32Bit FLOAT
19
Gen V-W voltage [V] (Line voltage)
32Bit FLOAT
21
Gen W-U voltage [V] (Line voltage)
32Bit FLOAT
23
Power factor [P.F]
32Bit FLOAT
25
Active power [kW]
32Bit FLOAT
27
Reactive power [kvar]
32Bit FLOAT
29
Apparent power [kVA]
32Bit FLOAT
31
Frequency [Hz]
32Bit FLOAT
33
kW Hour [kWh]
32Bit FLOAT
35
kvar Hour [kvarh]
32Bit FLOAT
