IDLE RUNNING 6.6.
- If [IDLE STATUS] is being input or [IDLE TIME] is set, status will switch to [IDLE RUNNING].
- If [IDLE STATUS] is not being input, or [IDLE TIME] is 0, status will switch to [BUILD-UP].
- [C_IDLE SPEED] will output even during [CRANK-ON], [CRANK-CHECK].
Menus that are influenced
Setup
Description
[DI-CONFIG] → [IDLE STATUS]
USE
[C_IDLE SPEED] during [IDLE STATUS]
[CONTROL] → [IDLE TIME]
0 ~ 60[s]
[IDLE RUNNING] until set time
BUILD-UP 6.7.
- Check to see if RPM, Frequency and Voltage have reached the nominal range of user set value.
- If 3 conditions meet, status will switch to [RUNNING]
- If Gen-set check is not completed within [BUILD-UP TIME], [FAIL TO BUILD-UP] ALARM will output.
Menus that are influenced
Setup
Description
[CONTROL] → [BUILD-UP TIME]
5 ~ 600[s]
Build-up checking time during set time
[PROTECTION] → [OVER SPEED],
[UNDER SPEED]
User setup
RPM check of user set range
[PROTECTION] → [OVER
FREQUENCY], [UNDER FREQUENCY]
User setup
Frequency check of user set range
[PROTECTION] → [OVER VOLTAGE],
[UNDER VOLTAGE]
User setup
Voltage check of user set range
RUNNING 6.8.
- If breaker trip situation does not occur, breaker can open/close automatically or manually according to
user set value.
- If Gen-set stop signal is input in [AUTO] and [MANUAL] mode, status will switch to [COOLDOWN].
- If stopped during [MANUAL] operation, engine will stop after Cool Down process. To stop immediately,
press the [STOP] button twice.
COOLDOWN 6.9.
- Operates in [AUTO] and [Manual] mode.
- No-load run during [COOLDOWN TIME] and then status will switch to [STOP].
- Press the stop button twice in [MANUAL] mode, it will stop immediately.
- [C_BREAKER OPEN] will output.
- If Gen-set start signal is input, status will switch to [RUNNING].
Menus that are influenced
Setup
Description
[CONTROL] → [COOLDOWN]
0 ~ 600[s]
[COOLDOWN] during
set time
