6. Operation Sequence
Control Function According to Operation Mode. 6.1.
Functions
BLOCK
MANUAL
AUTO
FIRE
LCD Screen
[BLOCK]
[MANUAL]
[AUTO]
[FIRE-RUN]
LED Indicator
BLOCK : ON
MANUAL : OFF
AUTO : OFF
BLOCK : OFF
MANUAL : ON
AUTO : OFF
BLOCK : OFF
MANUAL : OFF
AUTO : ON
BLOCK : OFF
MANUAL : ON
AUTO : ON
Mode Select
[MODE]
Button
[MODE] Button
[MODE] Button
Arbitrary setup
impossible
Select Mode
Non Applicable
Possible
Possible
Possible
Gen-Set Start
Impossible
[START] Button
Mains Off
Continuous Input
Gen-Set Stop
Non Applicable
[STOP] Button
Mains On
No Input
Protection
Partly Possible
Possible
Possible
Possible
ACB Control
Non Applicable
[CLOSE], [OPEN]
Button
Auto
Auto
Cooldown
Non Applicable
Impossible
Possible
Possible
Change
Parameter
Possible
Partly Possible
Partly Possible
Partly Possible
Fault History
Delete
Possible
Impossible
Impossible
Impossible
MODBUS Comm
Possible
Possible
Possible
Possible
Operation Order
6.2.
- Sequence of generator operation as shown below.
Order
Item
Description
1
[READY]
Ready to run
2
[PRE-CRANK]
When[PRE-CRANK TIME]is set, DO-CONFIG [C_PRE-CRANK] will
output
3
[CRANK-ON]
Start
4
[CRANK-OFF]
In case of start failure, standby until next start
5
[IDLE RUN]
IDLE run
6
[BUILD-UP]
Voltage, Frequency, and RPM waiting time to fall within rated range
7
[RUNNING]
Nominal run status, Load run possible
8
[COOLDOWN]
Cool down
9
[STOP]
Stop
Ready 6.3.
- In order to be in [READY] status to start Gen-set, following 3 conditions must meet.
- If following conditions do not meet, status will switch to [CHECK] mode and,
[C_CRANK] will not output.
- If status is [CHECK] in [AUTO] mode, [F_FAIL TO STOP] Alarm situation will occur.
