3. LCD Display Status
Start Screen 3.1.
- When power is on, start screen will show product number and program version.
Main Screen 3.2.
- When program booting is completed from Start screen, it will switch to Main screen.
- Main screen displays main information of Gen-set.
- Main screen displays 4 lines which are as shown below.
Seq
Description
1
st
Line
Operation Mode, Sequence Status, Sequence Timer
2
nd
Line
Information on screen are changeable with [◀], [▶] buttons
- Active power(kW), Gen-set voltage[V], Gen-set current[A], Power factor
- Active power(kW, %), Gen-set voltage[V], Gen-set current[A]
3
rd
Line
Information on screen changeable with [◀], [▶] buttons
- Frequency[Hz], [Rpm], Battery Voltage[V]
- Gen-set voltage[V], Gen-set phase voltage[V], Gen-set current[A],
Ground current[A]
- Apparent power[kVA], Reactive power[kvar], Power factor
- Mains voltage[V]
- Coolant temp[℃], Oil press[bar], Oil temp[℃], User temp[℃], Fuel level [%]
- Running hour[h], Integrating wattmeter[kWh], Reactive varmeter[kvar]
- Current date, time
4
th
Line
DI-CONFIG 01~10, DO-CONFIG 1~8, BUS or UVR signal timer
(BUS or UVR signal timer will only output in [AUTO] mode)
1
st
Line 3.2.1.
- 1st line of Main screen displays Operation Status, Sequence Status, and Sequence Timer.
2
nd
line 3.2.2.
- Information on 2
nd
line changeable with [▶], [◀] buttons on Main screen.
3
rd
Line 3.2.3.
- Information on 3
rd
line changeable with [▶], [◀] buttons on Main screen
4
th
Line 3.2.4.
- DI-CONFIG 01~10, DO-CONFIG 1~8, BUS or UVR SIGNAL timer displayed.
- BUS or UVR SIGNAL will only output in [AUTO] mode.
