ICD NeoGCP i7 PLUS+ - When Using EP20

REV. N
NeoGCP i7 PLUS+
- 31 -
When Using EP20 8.4.
- When using EP20, press [▶] button to switch to Ext-Module sensor setup screen.
Menu
Description
Factory Sensor Data
Type
EXT-MODULE
SENSOR 1
Not use, Coolant temp, Coolant
temp LH, Coolant temp RH, Oil
temp, User temp 1, User temp 2
DAEWOO Temp Sensor
(Recommended use of
temp sensor)
(PT100 recommended in
user temp setup)
Resistance
type
EXT-MODULE
SENSOR 2
EXT-MODULE
SENSOR 3
EXT-MODULE
SENSOR 4
EXT-MODULE
SENSOR 5
Not use, Oil press, Oil press LH, Oil
press RH, User press 1, User press 2
VDO press sensor
(Press Sensor
recommended)
EXT-MODULE
SENSOR 6
EXT-MODULE
SENSOR 7
Not use, Fuel level, Coolant level
-
Current
type
EXT-MODULE
SENSOR 8
- Keep pressing [▼] button to switch to Ext-Module sensor data screen from [SENSOR-SET] screen.
- Initial setup for [EXT-MODULE SENSOR 1] ~ [EXT-MODULE SENSOR 4] are data of temp sensor and
[EXT-MODULE SENSOR 5] ~ [EXT-MODULE SENSOR 6] are data of press sensor.
- Check sensor type, sensor data and setup value before using.
- DAEWOO Temp Sensor Setup
Resistance
1440
154
104
73
52
28
16
12
Temp
10
50
60
70
80
100
120
130
- VDO Temp Sensor Setup
Resistance
292
134
70
51
39
29
22
0
Temp
40
60
80
90
100
110
120
130
- PT 100 Temp Sensor Setup
Resistance
100
108
116
123
131
139
147
155
Temp
0
20
40
60
80
100
120
140
- PT 1000 Temp Sensor Setup
Resistance
1000
1078
1156
1234
1312
1391
1469
1547
Temp
0
20
40
60
80
100
120
140
