ICD NeoGCP i7 PLUS+ - Comm Protocol- MODBUS; Modbus Protocol

REV. N
NeoGCP i7 PLUS+
- 57 -
18. Comm Protocol- MODBUS
MODBUS PROTOCOL 18.1.
Items
Setup
Protocol Type
MODBUS RTU
Communication configuration
RS485 Half Duplex
Device ID Setup
0 ~ 255
Baud Rate Setup
9600, 19200, 38400 [bps]
Parity Setup
Even, Odd, None
Data Bit
8 [bit]
Stop Bit
1 [bit]
Support Function Code
Request(04h), Command(05h)
Frame-End Silent Interval
Firmware under V2.66 : 50 [ms], Firmware over V2.67 : 5
[ms]
REQUEST (04h) 18.1.1.
ADDRESS
DATA
TYPE
SCALE
01
SERIAL NUMBER
16bit UNSIGNED INT
1
02
PROGRAM VERSION
16bit UNSIGNED INT
/100
03
AVERAGE L-L GEN VOLTAGE
16bit SIGNED INT
1
04
AVERAGE L-N GEN VOLTAGE
16bit SIGNED INT
1
05
AVERAGE GEN CURRENT
16bit SIGNED INT
1
06
GEN U-V VOLTAGE [V]
16bit SIGNED INT
1
07
GEN V-W VOLTAGE [V]
16bit SIGNED INT
1
08
GEN W-U VOLTAGE [V]
16bit SIGNED INT
1
09
GEN U-N VOLTAGE [V]
16bit SIGNED INT
1
10
GEN V-N VOLTAGE [V]
16bit SIGNED INT
1
11
GEN W-N VOLTAGE [V]
16bit SIGNED INT
1
12
GEN U CURRENT [A]
16bit SIGNED INT
1
13
GEN V CURRENT [A]
16bit SIGNED INT
1
14
GEN W CURRENT [A]
16bit SIGNED INT
1
15
GEN GROUND CURRENT [A]
16bit SIGNED INT
1
16
MAINS R-S VOLTAGE [V]
16bit SIGNED INT
1
17
MAINS S-T VOLTAGE [V]
16bit SIGNED INT
1
18
ENGINE SPEED [RPM]
16bit SIGNED INT
1
19
FREQUENCY [Hz]
16bit SIGNED INT
/10
20
ACTIVE POWER [kW]
16bit SIGNED INT
1
21
APPARENT POWER [kVA]
16bit SIGNED INT
1
22
REACTIVE POWER [kvar]
16bit SIGNED INT
1
23
POWER FACTOR [P.F]
16bit SIGNED INT
/100
24
COOLANT TEMPERATURE [℃]
16bit SIGNED INT
1
25
OIL PRESSURE [bar]
16bit SIGNED INT
/10
26
OIL TEMPERATURE [℃]
16bit SIGNED INT
1
27
USER TEMPERATURE [℃]
16bit SIGNED INT
1
28
FUEL LEVEL [%]
16bit SIGNED INT
1
