ICD NeoGCP i7 PLUS+ - Sensor Related Fault Items

REV. N
NeoGCP i7 PLUS+
- 53 -
Sensor Related Fault Items 17.3.
Items
Alarm Level
Delay
Time
Sequence applied
Alarm
Level
Delay
Time
Sequence
applied
Alarm
Level
Delay
Time
COOLANT TEMP
HIGH
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
Coolant Temperature detected higher than set value
COOLANT TEMP
LOW
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
Coolant Temperature detected lower than set value
OIL PRESS HIGH
○
○
○
○
○
1[s]
BUILD-UP ~
COOLDOWN
Oil Pressure detected higher than set value
OIL PRESS LOW
○
○
○
○
○
1[s]
BUILD-UP ~
COOLDOWN
Oil Pressure detected lower than set value
OIL TEMP HIGH
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
Oil Temperature detected higher than set value
OIL TEMP LOW
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
Oil Temperature detected lower than set value
USER TEMP HIGH
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
User’s Temperature detected higher than set value
USER TEMP LOW
○
○
○
○
○
1[s]
RUNNING ~
COOLDOWN
User’s Temperature detected lower than set value
FUEL LEVEL HIGH
○
○
○
○
○
10[s]
Always
Fuel Level detected higher than set value
FUEL LEVEL LOW
○
○
○
○
○
10[s]
Always
Fuel Level detected lower than set value
COOLANT TEMP
SENSOR
◎
5[s]
Always
Coolant Temperature Sensor not connected
OIL PRESS
SENSOR
◎
5[s]
Always
Oil Pressure Sensor not connected
OIL TEMP
SENSOR
◎
5[s]
Always
Oil Temperature Sensor not connected
USER TEMP
SENSOR
◎
5[s]
Always
User’s Temperature Sensor not connected
FUEL LEVEL
SENSOR
◎
5[s]
Always
Fuel Level Sensor not connected
※ ◎ : Fixed item ○ : Optional item
