ICD NeoGCP i7 PLUS+ - Time Compensation (Clock); Sensor-Set; Sensor Use; Not Use; RTD Sensor Resistance Value and Output Setup

REV. N
NeoGCP i7 PLUS+
- 30 -
TIME COMPENSATION (CLOCK) 7.22.
- Adjust when time goes faster or slower.
- Setup : -31 ~ +31
8. SENSOR-SET
- Setup Sensor information needed in Gen-set run.
- Setup possible in Stop mode. (Some menus excluded)
Menu
Description
Setup
COOLANT TEMP
SENSOR
CT
Coolant temp sensor
Use, Not Use
OIL PRESS SENSOR
OP
Oil press sensor
Use, Not Use
OIL TEMP SENSOR
OT
Oil temp sensor
Use, Not Use
USER TEMP SENSOR
UT
User temp sensor
Use, Not Use
FUEL LEVEL SENSOR
FL
Fuel level sensor
Use, Not Use
COOLANT TEMP
LV1~LV8
V1~V8
Setup temp according to
resistance value of sensor
0~2000 [Ω] / 0~150℃
OIL PRESS LV1~LV8
V1~V8
Setup press according to
resistance value of sensor
0~2000 [Ω] / 0.0 ~16.0 [bar]
OIL TEMP LV1~LV8
V1~V8
Setup temp according to
resistance value of sensor
0~2000 [Ω] / 0~150℃
USER TEMP LV1~LV8
V1~V8
Setup temp according to
resistance value of sensor
0~2000 [Ω] / 0~150℃
FUEL LEVEL GAIN
GAIN
Setup fuel level Gain
0.001 ~ 9.999
FUEL LEVEL OFFSET
OFFSET
Setup fuel level Offset
0 ~ 9999
Sensor Use / Not use 8.1.
- Setup Coolant temp, Oil press, Oil temp, User temp, Use / Not use of fuel level sensor.
- Setup : Use, Not use
RTD Sensor Resistance Value and Output setup 8.2.
- Setup output value of sensor according to RTD Sensor resistance value.
- Setup : Set output value according to V1 ~ V8
Fuel Level Gain and Offset 8.3.
- 4~20 [mA] Set digital output value of fuel level sensor analog input value.
- Gain : 0.001 ~ 9.999
- Offset : 0 ~ 9999
