7. SYSTEM
- Setup of basic information to run Gen-set.
- Setup possible in stop mode. (Some menus excluded)
Menu
Description
Setup
POWER
P
Input rated kW of GEN-SET
0 ~ 5000 [kW]
FREQUENCY
F
Input Rated Frequency of GEN-
SET
40 ~ 60 [Hz]
VOLTAGE
V
Input Rated Voltage of GEN-SET
110 ~ 6600 [V]
CURRENT
I
Input Rated Current of GEN-SET
5 ~ 9999 [A]
GR CURRENT
GRI
Input Ground Current of GEN-
SET
5 ~ 9999 [A]
GEN WIRING
WIRE
Select Generator Wiring Type
1P-2W / 1P-3W / 3PHASE
EXT-MODULE
EX
EXT-Module Use/ Not use
Not use / EM20 / EP20
ECU TYPE
EP
Setup ECU Type
Not use / EMSS6 / EDC7
PT RATIO
PT
Input PT Ratio
1.00 ~ 99.99
CT RATIO
CT
Input CT Ratio
5/1 ~ 9999/5
GR CT RATIO
ZCT
Input ZCT Ratio
5/1 ~ 9999/5
ENGINE RPM
RPM
Input RPM of GEN-SET
0 ~ 4000
GOVERNOR TYPE
GOV
Input Governor Type
Fuel / Stop
TEETH(FACTOR)
TEETH
Input Engine Gear Teeth
0 ~ 250
BREAKER TYPE
TYPE
Setup Breaker Type
MCCB / ACB / MC
BREAKER AUX CHECK
AUX
Setup Breaker Auxiliary contact
Use / Not use
BUTTON BEEP
BEEP
Setup Button Sound
Use / Not use
ALARM HORN TIME
HORN
Setup Alarm Sound Output Time
0 ~ 600 [s]
BACK-LIGHT TIME
LIGHT
Setup Back-light Holding Time
0 ~ 600 [s]
DATE SETUP
DATE
Setup Present Date
TIME SETUP
TIME
Setup Present Time
00:00 ~ 23:59
TIME COMPENSATION
CLOCK
Adjust Clock
-31 ~ +31
POWER (P) 7.1.
- Setup rated output of Gen-set.
- Setup : 0 ~ 5000 [kW]
FREQUENCY (F) 7.2.
- Setup frequency of Gen-set.
- Setup : 40 ~ 60 [Hz]
VOLTAGE (V) 7.3.
- Setup rated voltage(line voltage) of Gen-set.
- Setup : 110 ~ 6600 [V]
