ICD NeoGCP i7 PLUS+ - Current (I); Gr Current (Gri); Gen Wiring (Wire); Ext-Module (Ex)

REV. N
NeoGCP i7 PLUS+
- 26 -
CURRENT (I) 7.4.
- Setup rated current of Gen-set.
- Setup : 5 ~ 9999 [A]
Rated Current Formula
Rated Current[A] = Rated Output[kW] ÷ {1.732 × Rated Voltage[V] × 1000 × Power
Factor(cosθ)}
GR CURRENT (GRI) 7.5.
- Setup ground current of Gen-set.
- Setup : 5 ~ 9999 [A]
GEN WIRING (WIRE) 7.6.
- Setup wiring type of Gen-set.
- Setup : 1P-2W, 1P-3W, 3PHASE
- Wiring differs according to wiring type of Generator.
EXT-MODULE (EX) 7.7.
- Setup EXT-MODULE use/ not use.
- Setup : Not use, EM20, EP20
- Purchase of additional I/O ports is possible for EXT-MODULE.
- When using EXT-MODULE, number of additional setup will increase.
- Refer to EXT-MODULE manual for details.
Setup
Menus that are influenced
Description
Not use
[DI-CONFIG]
[DI 01 SET] ~ [DI 10 SET]
[DO-CONFIG]
[DO 01 SET] ~ [DO 08 SET]
EM20
[DI-CONFIG]
[DI 01 SET] ~ [DI 18 SET]
[DO-CONFIG]
[DO 01 SET] ~ [DO 16 SET]
EP20
[DI-CONFIG]
[DI 01 SET] ~ [DI 18 SET]
[DO-CONFIG]
[DO 01 SET] ~ [DO 72 SET]
[SENSOR-SET]
[EXT-MODULE SENSOR 11] ~ [EXT-
MODULE SENSOR 18] Use/ Not use
[EXT-MODULE SENSOR 1] ~ [EXT-MODULE
SENSOR 8] data
[PROTECTION]
[EXT-MODULE SENSOR 11] ~ [EXT-
MODULE SENSOR 18] Alarm setup
EP20-1~8
EXT-MODULE can be expanded up to 8
