ICD NeoGCP i7 PLUS+ - Pre-Crank; Crank On;Off

REV. N
NeoGCP i7 PLUS+
- 20 -
Conditions
Menus that are influenced
Description
RPM
-
Should be 0 [RPM]
Oil Press
Sensor
[CONTROL] → [RUN-STATE OP-GAUGE]
[0] and up: lower than set value
[0] : No check
Oil Press
switch
[CONTROL] → [[RUN-STATE OP-SWITCH]
[USE] : Should be Oil Press Low
[NOT USE] :No check
PRE-CRANK 6.4.
- When Gen-set start signal is [READY], [C_PRE- CRANK] will output and then status will switch to [PRE-
CRANK].
- If [PRE-CRANK TIME] reaches 0, status will switch to [CRANK-ON] after Gen-set start signal input.
Menus that are influenced
Setup
Description
[CONTROL] → [PRE-CRANK TIME]
0 ~ 60 [s]
[C_PRE-CRANK] will output during set time
CRANK ON/OFF 6.5.
- [C_CRANK] will output to run Gen-set.
- If one of the conditions such as [RUN-STATE RPM], [RUN-STATE OP-GAUGE],
[RUN-STATE OP-SWITCH] meet, status will switch to [IDLE RUNNING].
- If 3 conditions do not meet, status will switch to [STOP] in [MANUAL] mode and in [AUTO] or [FIRE]
mode, Gen-set will start for a set number of times and then [FAIL TO START] alarm situation will occur.
- If [TEETH(FACTOR)] is 30, separate [CRANK-CHECK] time will countdown for 5 seconds after [CRANK-
ON] and then will check Run-state.
Item
Menus that are influenced
Description
Run-
State
[CONTROL] → [RUN-STATE RPM]
Should be higher than set value
[CONTROL] → [RUN-STATE OP-
GAUGE]
[0] and up: higher than set value
[0] : No check
[CONTROL] → [RUN-STATE OP-
SWITCH]
[USE] : Should not be low oil pressure
status
[NOT USE] :No check
Crank
Attempts
[CONTROL] → [CRANK-ON TIME]
[C_CRANK] output time
[CRANK-CHECK]
Fixed for 5[s] if [TEETH(FACTOR)] is 30
[CONTROL] → [CRANK-OFF TIME]
Delay time until next crank
[CONTROL] → [CRANK ATTEMPTS]
Number of cranking repeat in [AUTO]
mode
