STOP 6.10.
- [STOP], then switch to [READY].
- Check of stop status when using [PROTECTION] → [FAIL TO STOP].
- If RPM, Oil press sensor, Oil press switch are not in stop status until [STOP-HOLD TIME] reaches 0,
[F_FAIL TO STOP] Alarm will output.
Item
Menus that are influenced
Description
Stop Failure
[PROTECTION] → [FAIL TO STOP]
Setup Use/Not use
RPM
-
Should be 0 [RPM]
Oil Press
Sensor
[CONTROL] → [RUN-STATE OP-GAUGE]
[0] and up: lower than set value
[0] : No check
Oil Press
Switch
[CONTROL] → [RUN-STATE OP-SWITCH]
[USE] : Should be Oil Press Low
[NOT USE] : No check
MANUAL 6.11.
- [START], [STOP], [BREAKER CLOSE], [BREAKER OPEN] can be controlled manually.
- [COOLDOWN TIME] will be applied. If the [STOP] button is pressed during Cool Down process, it stops
immediately without cooling.
- [MANUAL] will be displayed on LCD and [MANUAL] LED will be lit.
- If Breaker type is ACB, running sequence is as shown below.
Order
Button
Description
1
[MODE]
Switch to [MANUAL] mode
2
[START]
Gen-set run
3
[BREAKER CLOSE]
Breaker Close → Load Run
4
[BREAKER OPEN]
Breaker Open → No-load Run
5
[STOP]
Gen-set Stop
AUTO 6.12.
- Controls generator automatically, and [START], [STOP], [BREAKER CLOSE], [BREAKER OPEN] buttons
will not activate.
- [AUTO] will be displayed on LCD and [AUTO] LED will be lit.
- If breaker type is ACB, refer to following example on the next page for general operation procedure.
FIRE 6.13.
- When [FIRE-RUN] is implemented, status will switch to [FIRE] mode and operation status will be same
as [AUTO] mode.
- [FIRE] will be displayed on LCD and [AUTO], [MANUAL] LED will be lit.
