ECU TYPE (EP) 7.8.
- NeoGCP g7 model with built-in CAN communication is recommended.
- Setup : Not use, EMSS6, EDC7, Volvo-EMSS2, 16V Baudouin, FIAT, PERKINS, DN03
- Must use a separate CAN converter sold by our company when using ECU type.
- If NeoGCP g7 model is used, the built-in CAN function can be used without a separate converter.
- When using ECU TYPE, previous setup value will be adjusted to relevant ECU.
If separate setup is needed, setup ECU TYPE first then change user setup.
Menus that will change when using EMSS6
After changes
[SENSOR-SET]
[COOLANT TEMP SENSOR]
Not use
[OIL PRESS SENSOR]
Not use
[OIL TEMP SENSOR]
Not use
[USER TEMP SENSOR]
Not use
[FUEL LEVEL SENSOR]
Not use
[EXT-MODULE SENSOR 1~8]
Not use
[CONTROL]
[IDLE TIME]
5[s]
[CRANK OFF TIME]
15[s]
[CRANK ON TIME]
15[s]
[PROTECTION]
[OIL PRESS LOW]
2.7 [bar]
[COOLANT TEMP HIGH]
103 [℃]
Menus that will change when using EDC7
After changes
[SENSOR-SET]
[COOLANT TEMP SENSOR]
Not use
[OIL PRESS SENSOR]
Not use
[OIL TEMP SENSOR]
Not use
[USER TEMP SENSOR]
Not use
[FUEL LEVEL SENSOR]
Not use
[EXT-MODULE SENSOR 1~8]
Not use
[CONTROL]
[IDLE TIME]
5[s]
[CRANK OFF TIME]
15[s]
[AUTO STOP DELAY]
10[s]
[PROTECTION]
[OIL PRESS LOW]
0.5 [bar]
[COOLANT TEMP HIGH]
103 [℃]
[OIL TEMP HIGH]
103 [℃]
PT RATIO (PT) 7.9.
- Setup PT( Potential Transformer) Ratio.
- Setup : 1 ~ 99.99
- If Gen-set rated voltage exceeds AC 550 [Vrms], PT must be used.
- Ex) When 1
st
PT voltage (Gen-set voltage) is 6600 [V], and when PT 2
nd
voltage (Input voltage) is 110
[V].
