ICD NeoGCP i7 PLUS+ - Gen Start; Gen Stop; Breaker Close; Breaker Open

REV. N
NeoGCP i7 PLUS+
- 37 -
GEN START 9.20.
- Used as Gen-set start contact.
- Gen-set will start when contact is input in [MANUAL], [READY].
- Gen-set will not stop even if contact is open after start.
- Setup : TYPE(N/O, N/C),
GEN STOP 9.21.
- Used as Gen-set stop contact.
- Gen-set will stop when contact is input in [MANUAL] mode.
Gen-set will not run even if contact is open after stop.
- Setup : TYPE(N/O, N/C),
BREAKER CLOSE 9.22.
- Used as breaker close contact.
- If it is not breaker trip alarm situation in [RUN] of [MANUAL] mode, breaker will close when signal is
input.
- Breaker will close in [AUTO], [SCHEDULED-RUN], [SCHEDULED-RUN ACB CONTROL-MANUAL] when
signal is input.
- Setup : TYPE(N/O, N/C),
Menus that are influenced
Setup
Description
[CONTROL] → [SCHEDULED-RUN ACB
CONTROL]
[MANUAL]
ACB manual control in scheduled-
run
BREAKER OPEN 9.23.
- Used as breaker open contact.
- Breaker will open in [MANUAL], [RUN], [COOLDOWN], [STOP] when signal is input.
- Breaker will open in [AUTO], [SCHEDULED-RUN], [SCHEDULED-RUN ACB CONTROL-MANUAL] when
signal is input.
- Setup : TYPE(N/O, N/C)
Menus that are influenced
Setup
Description
[CONTROL] → [SCHEDULED-RUN ACB
CONTROL]
[MANUAL]
ACB manual control in scheduled-
run
