11. CONTROL
- Setup Gen-set operation status.
Items
Description
Setup
MAINS SENSING
TYPE
Setup Mains Sensing method
R-S, R-S-T ,
UVR
AUTO-START
DELAY
T1
Auto-Start delay time when Mains Off
0 ~ 7200 [s]
AUTO-STOP DELAY
TIME
T2
Auto-Stop delay time when Mains On
0 ~ 7200 [s]
AUTO-START
VOLTAGE
V1
Setup voltage level to recognize as Mains
off when Mains Sensing is ‘MAIN R-S’ or
‘MAIN R-S-T’
0 ~6600 [V]
AUTO-STOP
VOLTAGE
V2
Setup voltage level to recognize as Mains
On when Mains Sensing is ‘MAIN R-S’ or
‘MAIN R-S-T’
0 ~ 6600 [V]
SCHEDULED-RUN
TYPE
Setup use/not use and using method of
Scheduled-Run
Not use, date,
day
SCHEDULED-RUN
SETUP
SETUP
Setup date when Scheduled-Run is [DATE]
Setup day when Scheduled-Run is [DAY]
0 ~ 31
month, date
SCHEDULED-RUN
ACB CONTROL
CB
Setup ACB control type in Scheduled-Run
Manual, Auto
SCHEDULED-RUN
START
ON
Setup start time of Scheduled-Run
00:00 ~ 23:59
SCHEDULED-RUN
OFF
OFF
Setup stop time of Scheduled-Run
00:00 ~ 23:59
PRE-CRANK TIME
PRE
Relay output time of Pre-Crank
0 ~ 60 [s]
CRANK-ON TIME
ON
Crank max output time
1 ~ 9 [s]
CRANK-OFF TIME
OFF
Delay time until next crank when repeating
5 ~ 60 [s]
CRANK
ATTEMPTS(AUTO)
REPEAT
Number of Crank repeat in AUTO Mode
1 ~ 9 [s]
RUN-STATE RPM
RPM
RPM to check engine crank
No check when set to 0 (initial value 400)
100 ~ 1200
[rpm]
RUN-STATE OP-
GAUGE
OPG
Oil press to check engine crank
No check when set to 0
0.0 ~ 16.0
[bar]
RUN-STATE OP-
SWITCH
OPS
Use/Not use of oil press switch to check engine
crank
Use, Not use
OIL PRESS DEAD-
TIME
OPDT
Delay time of oil press low protection after
engine crank
0 ~ 30 [s]
GOV DELAY TIME
GOV
Delay time of [C_GOVERNOR] output after
[C_CRANK] output
0 ~ 99 [s]
IDLE TIME
IDLE
Setup time for IDLE-RUN
IDLE Relay will output during set time
0 ~ 60 [s]
BUILD-UP EXPIRE
BUILD-UP
If voltage, frequency, and RPM don’t build-
up within set time after cranking, Build-up
Failure fault will occur
5 ~ 600 [s]
ACB CLOSE DELAY
CLOSE
ACB Close delay time in AUTO Mode
0 ~ 60 [s]
