Digital Input Related Fault 17.4.
Items
Alarm Level
Delay
Time
Sequence applied
Alarm
Level
Delay
Time
Sequence
applied
Alarm
Level
Delay
Time
DI 1 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #1 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 2 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #2 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 3 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #3 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 4 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #4 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 5 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #5 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 6 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #6 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 7 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #7 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 8 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #8 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 9 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #9 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
DI 10 USER
FAULT
○
○
○
○
○
Setup
Always
When DI #10 is set as USER FAULT, USER FAULT(RUN), USER FAULT(STOP)
input message will be displayed
※ ◎ : Fixed item ○ : Optional item
EP20 Related Alarm 17.5.
- If communication does not occur within 5 seconds, EP20 comm alarm will output.
- If EP20 comm alarm occurs, [C_CRANK] will not output.
Items
Alarm Level
Delay
Time
Sequence Applied
Not
use
Warning
Trip
Stop
Shutdown
EP20 Comm
Alarm
◎
5[s]
Always
When communication with EP20 does not occur within 5 seconds.
