ICD NeoGCP i7 PLUS+ - Page 60

REV. N
NeoGCP i7 PLUS+
- 60 -
Note6 ) BIT FIELD
BIT
67
68
0
USER TEMP SENSOR 2 HIGH
USER TEMP 2 SENSOR FAULT
1
USER TEMP SENSOR 2 LOW
COOLANT TEMP LH SENSOR FAULT
2
COOLANT TEMP LH HIGH
COOLANT TEMP RH SENSOR FAULT
3
COOLANT TEMP LH LOW
OIL PRESS LH SENSOR FAULT
4
COOLANT TEMP RH HIGH
OIL PRESS RH SENSOR FAULT
5
COOLANT TEMP RH LOW
USER PRESS 1 SENSOR FAULT
6
OIL PRESS LH HIGH
USER PRESS 2 SENSOR FAULT
7
OIL PRESS LH LOW
COOLANT LEVEL SENSOR FAULT
8
OIL PRESS RH HIGH
COOLANT TEMP LH SWITCH
9
OIL PRESS RH LOW
COOLANT TEMP RH SWITCH
10
USER PRESS 1 HIGH
OIL PRESS LH SWITCH
11
USER PRESS 1 LOW
OIL PRESS RH SWITCH
12
USER PRESS 2 HIGH
EXT-MODULE COMM FAULT
13
USER PRESS 2 LOW
ECU COMM FAULT
14
COOLANT LEVEL HIGH
ECU OIL PRESS SWITCH FAULT
15
COOLANT LEVEL LOW
ECU COOLANT TEMP HIGH S/W FAULT
CONTROL (05h) 18.1.2.
ADDRESS
DATA
VALUE
0001
STOP
0xFF00
0002
START
0003
RESET
0005
MODE
0006
BLOCK
0007
MANUAL
0008
AUTO
0009
CLOSE
0010
OPEN
Comm example 18.1.3.
Request
Response
DATA(h)
Description
DATA(h)
Description
02
Address
02
Address
04
Function
04
Function
00
Starting address Hi
14
Byte count
00
Starting address Lo-
1
00
Data Hi
00
Num of registers Hi
00
Data Low
0A
Num of registers Lo
-
XX
CRC
XX
CRC
XX
XX
