ICD NeoGCP i7 PLUS+ - Page 59

REV. N
NeoGCP i7 PLUS+
- 59 -
12
-
-
-
13
-
-
-
14
-
-
-
15
-
-
-
Note5 ) BIT FIELD
BIT
39
40
41
42
43
0
OVR
OSR
COOLANT
TEMP HIGH
DI 1 User Fault
DI 11 Input
Fault
1
UVR
USR
COOLANT
TEMP LOW
DI 2 Input
Fault
DI 12 Input
Fault
2
OCR (INSTANT)
EMERGENCY
STOP
OIL PRESS
HIGH
DI 3 Input
Fault
DI 13 Input
Fault
3
OCR
(CONSTANT)
FAIL TO START
OIL PRESS
LOW
DI 4 Input
Fault
DI 14 Input
Fault
4
OCR (INVERSE)
FAIL TO STOP
OIL TEMP
HIGH
DI 5 Input
Fault
DI 15 Input
Fault
5
OCGR(DI)
FAIL TO
STOP(RPM)
OIL TEMP
LOW
DI 6 Input
Fault
DI 16 Input
Fault
6
OCGR(SET)
FAIL TO STOP(OP
GAUGE)
USER TEMP
HIGH
DI 7 Input
Fault
DI 17 Input
Fault
7
OCGR(CONSTAN
T)
FAIL TO STOP(OP
SWITCH)
USER TEMP
LOW
DI 8 Input
Fault
DI 18 Input
Fault
8
OCGR(INVERSE)
COOLANT TEMP
HIGH S/W
FUEL LEVEL
HIGH
DI 9 Input
Fault
-
9
OFR
OIL PRESS LOW
S/W
FUEL LEVEL
LOW
DI 10 Input
Fault
-
10
UFR
NO CHARGING
S/W
SENSOR1
FAULT
-
-
11
FAIL TO BUILD-
UP
COOLANT LEVEL
S/W
SENSOR2
FAULT
-
-
12
BREAKER AUX
FAILURE
BAT VOLTAGE
HIGH
SENSOR3
FAULT
-
-
13
-
BAT VOLTAGE
LOW
SENSOR4
FAULT
-
-
14
-
MPU FAILURE
SENSOR5
FAULT
-
-
15
-
-
-
-
-
