Note6) BIT FIELD
BIT
01
02
03
0
OVR
Gen-set start
-
1
UVR
Auto Mode
-
2
OCR
-
-
3
OCGR
-
-
4
OSR
Breaker open
Output
-
5
Coolant Temp High
Breaker close
output
-
6
Oil Press Low
Breaker open
contact input
-
7
Fail to Start, Fail to
Stop
Breaker close
contact input
-
8
DI 3 Input Alarm
DO 1 Output
Sys Error – Breaker aux alarm, Low battery
voltage
9
DI 4 Input Alarm
DO 2 Output
Alarm – Setup when alarm occurs
10
DI 5 Input Alarm
DO 3 Output
Event – Not use
11
DI 6 Input Alarm
DO 4 Output
-
12
DI 7 Input Alarm
DO 5 Output
Remote / Local – Not use
13
DI 8 Input Alarm
DO 6 Output
-
14
DI 9 Input Alarm
DO 7 Output
-
15
DI 10 Input Alarm
DO 8 Output
Setup when using SWAP SET – WORD
SWAP
CONTROL (05h) 18.2.2.
ADDRESS
DATA
VALUE
0002
BREAKER CLOSE
0xFF00
0004
BREAKER OPEN
0006
START
0010
STOP
0014
BREAKER CLOSE
0018
BREAKER OPEN
0022
BLOCK MODE
0026
MANUAL MODE
0030
AUTO MODE
0034
ALARM RELEASE
