NeoGCP i7 PLUS+
- 49 -
Items
Description
Setup
COOLANT
TEMP HIGH
HIGH
Setup level for Coolant Temp High
0 ~ 150 [℃]
ALARM
Setup protection level for Coolant Temp
High
Refer to chart below
COOLANT
TEMP LOW
LOW
Setup level for Coolant Temp Low
0 ~ 150 [℃]
ALARM
Setup protection level for Coolant Temp
Low
Refer to chart below
OIL PRESS HIGH
HIGH
Setup level for Oil Press High
0.0 ~ 16.0 [bar]
ALARM
Setup protection level for Oil Press High
Refer to chart below
OIL PRESS LOW
LOW
Setup level for Oil Press Low
0.0 ~ 16.0 [bar]
ALARM
Setup protection level for Oil Press Low
Refer to chart below
OIL TEMP HIGH
HIGH
Setup level for Oil Temp High
0 ~ 150 [℃]
ALARM
Setup protection level for Oil Temp High
Refer to chart below
OIL TEMP LOW
LOW
Setup level for Oil Temp Low
0 ~ 150 [℃]
ALARM
Setup protection level for Oil Temp Low
Refer to chart below
USER TEMP
HIGH
HIGH
Setup level for User Temp High
0 ~ 150 [℃]
ALARM
Setup protection level for User Temp
High
Refer to chart below
USER TEMP
LOW
LOW
Setup level for User Temp Low
0 ~ 150 [℃]
ALARM
Setup protection level for User Temp
Low
Refer to chart below
FUEL LEVEL
HIGH
HIGH
Setup level for Fuel Level High
0 ~ 100 [%]
ALARM
Setup protection level for Fuel Level High
Refer to chart below
FUEL LEVEL
LOW
LOW
Setup level for Fuel Level Low
0 ~ 100 [%]
ALARM
Setup protection level for Fuel Level Low
Refer to chart below
BAT VOLTAGE
HIGH
HIGH
Setup level for Battery Voltage High
8 ~ 35 [V]
ALARM
Setup protection level for Battery
Voltage High
Refer to chart below
BAT VOLTAGE
LOW
LOW
Setup level for Battery Voltage Low
8 ~ 35 [V]
ALARM
Setup protection level for Battery
Voltage Low
Refer to chart below
STOP FAILURE
SET
Setup Stop Failure
Use, Not use
- Setup possible alarm levels are as follows.
Alarm types
ALARM
BREAKER OPEN
COOLDOWN
STOP
NOT USE
-
-
-
-
WARNING
○
-
-
-
TRIP
○
○
-
-
STOP
○
-
○
○
SHUTDOWN
○
-
-
○
TRIP+STOP
○
○
○
○
TRIP+SHUTDOWN
○
○
-
○
