ICD NeoGCP i7 PLUS+ - Page 48

REV. N
NeoGCP i7 PLUS+
- 48 -
Items
Description
Setup
OVR
SET
Setup level for over voltage
100 ~ 150 [%]
DELAY
Setup constant delay time for over voltage
0.5 ~ 20.0 [s]
LEVER
Setup inverse lever for over voltage
0.05 ~ 1.0
INST
Setup instant for over voltage
Use, Not use
ALARM
Setup protection level for over voltage
Refer to chart below
UVR
SET
Setup level for under voltage
50 ~ 100 [%]
DELAY
Setup delay time for under voltage
0.5 ~ 20.0 [s]
ALARM
Setup protection level for under voltage
Refer to chart below
OCR
SET
Setup for over current
101 ~ 200 [%]
DELAY
Setup delay time for over current
0.5 ~ 20.0 [s]
LEVER
Setup characteristics lever for over current
0.05 ~ 1.0
INST
Setup instant for over current
Use, Not use
ALARM
Protection level for over current
Refer to chart below
OCGR
SET
Setup level for OCGR
101 ~ 200 [%]
DELAY
Setup delay time for OCGR
0.5 ~ 20.0 [s]
LEVER
Setup characteristics lever for OCGR
0.05 ~ 1.0
INST
Setup instant for OCGR
Use, Not use
ALARM
Protection level for OCGR
Refer to chart below
OFR
SET
Setup level for over frequency
100 ~ 150 [%]
DELAY
Setup delay time for over frequency
0.5 ~ 20.0 [s]
ALARM
Protection level for over frequency
Refer to chart below
UFR
SET
Setup level for under frequency
50 ~ 100 [%]
DELAY
Setup delay time for under frequency
0.5 ~ 20.0 [s]
ALARM
Protection level for under frequency
Refer to chart below
OSR
SET
Setup level for Over Speed
100 ~ 150 [%]
DELAY
Setup delay time for Over Speed
0.1 ~ 1.0
ALARM
Setup protection level for Over Speed
Refer to chart below
USR
SET
Setup level for Under Speed
50 ~ 100 [%]
DELAY
Setup delay time for Under Speed
0.5 ~ 20.0 [s]
ALARM
Setup protection level for Under Speed
Refer to chart below
