Rev AA Maintaining the Printer 5-21
Adjusting the Cassette Latch
The latch components on the printer are set at the factory and normally do
not require adjustment.
If it is necessary to adjust the latch, proceed as follows.
1 Remove the cassette from the printer.
2 Remove any ribbon from the cassette.
3 Loosen the lock nut on the cassette latch (10 mm), as shown in
Figure 5-27.
Figure 5-27: Latch Screw Locking Nut Loosening
I
CE Pegasus Service Manual
