Ice PegasusHS User Manual

3-27
Default Options Configuration
Rev AA
Devices, Phds,1
Print Information
Continuous Multi Print Mode
None None No Enables Multi Print mode in continuous motion
printing. One print signal generates a number of prints, separated by a defined distance. Enabling this mode requires the user to also set the Continuous Prints per Signal, Continuous Repeat Distance and Continuous Registration Delay parameters correctly
Continuous Print Position
Print Position 0.01m
m
2100 Position of the printhead from its parked position,
when printing in continuous motion. Defines the position of the printhead relative to the print roller
Continuous Prints per Signal
None None 1 The number of prints per print signal when using
Continuous Multi Print Mode
Devices, Phds,1
Print Information
Continuous Registration Delay
Horizontal Registration
mm 0 The distance to delay the print after receipt of the
print signal. In Con ti no us Multi Print Mode this defines the distance to the first print.
Continuous Repeat Distance
None mm 100 The distance between successive prints in
Continuous Multi Print Mode
Encoder Scaling Percent
Encoder Scaling
% 100 Permits the machine to be run with a slightly
mismatched ribbon and substrate speed
Interleaved Images
Interleaved Images
None No Enables ribbon saving via interleaved images
Section Sub-Section Parameter
Name
CLARiTY Name
Units Default Functionality
Table 3-1: Videojet 6210 Printer Configuration Manager (Continued)
ICE Pegasus Service Manual
