Ice PegasusHS User Manual

Rev AA Default Options Configuration 3-28
Devices, Phds,1
Print Information
Intermittent Head Down Time
None mS 20 The time for the printhead to move from its ready to
print position to contact with the print pad in intermittent printing mode.
Intermittent Print Delay
None mS 500 The time to wait after receiving the print signal
before commencing an intermittent print.
Intermittent Print Registration
Horizontal Registration
mm 0 A print registration delay in the direction of the
printhead movement, effectively moving the print further from the starting point of printhead contact with the film.
Intermittent Start Border Tmm
None 0.1m
m
20 Distance moved by the printhead before starting to
print in intermittent mode. Used to compensate for any bouncing of the printhead as it hits the print pad.
Devices, Phds,1
Print Information
Maximum Re Print Gap
None mm 40 If the Low Speed Behavior is set to Resume on
Speedup, then if the bag moves a distance greater than this parameter, whilst in 'low speed', the coder prints a complete, whole code on the bag as soon as the film speed exceeds 65mm/s
Print Darkness Print
Darkness
% 75 Sets the amount of energy being sent to the
printhead
Devices, Phds,1
Print Information
Print Sensor Debounce
None mm 1 The distance of film that has to advance with the
print signal being 'on' before it is accepted. Used to avoid multiple erroneous print signals when a sensor or signal is not giving a clean switch. Works in conjunction with Print Sensor Debounce Time - the first to expire wins. Using the distance method of debouncing guarantees print registration, the time based system doesn't.
Section Sub-Section Parameter
Name
CLARiTY Name
Units Default Functionality
Table 3-1: Videojet 6210 Printer Configuration Manager (Continued)
ICE Pegasus Service Manual
