D DTCS code
Selects DTCS (both encoder/decoder) code for DTCS squelch
operation. Total of 104 codes (023–754) are available.
(default: 023)
• Available DTCS codes
D DTCS polarity
Sets DTCS polarity from “BOTH N” (TX/RX: normal), “TN-RR”
(TX: normal, RX: reverse), “TR-RN” (TX: reverse, RX: normal) and
“BOTH R” (TX/RX: reverse). (default: BOTH N)
Transmitting or receiving DTCS code’s polarity is sets by this
item at transmitting side and receiving side respectively.
D DTMF speed
Select the desired DTMF transmission speed from 100
msec, 200 msec, 300 msec, 500 msec.
• 100 : 100-msec. interval; 5.0 characters per second
(default)
• 200 : 200-msec. interval; 2.5 characters per second
• 300 : 300-msec. interval; 1.6 characters per second
• 500 : 500-msec. interval; 1.0 character per second
New2001
MENU SCREEN OPERATION
111
12
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
023
