Icom IC-92A - Gps Message Automatic Transmission

60
8
GPS/GPS-A OPERATION (Optional UT-121 is required for IC-92A)
New2001
D GPS message automatic transmission
q Enter “GPS AUTO TX” in DV set mode. (p. 95)
• GPS AUTO TX screen is displayed.
w Rotate [DIAL]
†
to select the desired position data trans-
mitting interval from 5 sec., 10 sec., 30 sec., 1 min., 3
min., 5 min., 10 min., 30 min. and OFF.
• The position data is transmitted only when [PTT] is pushed with
OFF setting, the data is transmitted automatically once every
5 sec., 10 sec., 30 sec., 1 min., 3 min., 5 min., 10 min. and 30
min. when the appropriate setting is selected.
• The GPS message is also transmitted if programmed.
e Push [ ](5) (or [ ](4)) to return to DV SET MODE screen.
r Push [MENU/
] to return to frequency indication.
NOTE: Your own call sign (“MY”) should be set to activate
the GPS automatic transmission.
D Received GPS message indication
q Enter “RX GPS” in message/position set mode.
• RX GPS MESSAGE screen is displayed.
w Push [
](5) (or [ ](4)) to return to MESSAGE/POSITION
screen.
e Push [MENU/
] to return to frequency indication.
Ne
❮MENU screen❯ ➪ ❮DV SET MODE❯ ➪ ❮GPS AUTO TX❯
(Push [MENU/
]) (Rotate [DIAL]
†
, then push [ ](5)
†
.)
OFF
OFF
5SEC
5SEC
10SEC
10SEC
30SEC
30SEC
1MIN
1MIN
GPS AUTO TX
r
❮MENU screen❯ ➪ ❮MESSAGE/POSITION❯ ➪ ❮RX GPS❯
(Push [MENU/
]) (Rotate [DIAL]
†
, then push [ ](5)
†
.)
DATA:
DATA:
Call from
Call from
Osaka!
Osaka!
:BACK
:BACK
RX GPS MESSAGE
r
[NOTICE]
USE GPS message automatic transmission at simplex mode.
Sending with GPS message automatic transmission through the
repeater may interfere with other amateur radio.
[NOTICE]
“5SEC” cannot select when 4 GPS sentences are selected.
