Icom IC-92A - Function Display

6
2
PANEL DESCRIPTION
New2001 Ne
■ Function display
q BATTERY INDICATOR (pgs. 10, 12)
➥ “ ” (battery indicators) appear when the Li-Ion bat-
tery pack is attached.
➥ “ ” appears when the battery pack must be charged.
➥ The indicators show “ ,” “ ” and “ ” in se-
quence while charging the attached battery pack.
w DUPLEX INDICATORS (p. 29)
“ +DUP” appears when plus duplex, “–DUP” appears when
minus duplex is selected.
e PRIORITY WATCH INDICATOR (p. 83)
Appears when priority watch is in use.
r TONE INDICATORS
• While operating in FM mode;
➥ “ TONE” appears while the subaudible tone encoder is
in use. (pgs. 29, 106)
➥ “ TSQL” appears while the tone squelch function is in
use. (p. 110)
➥ “ DTCS” appears while the DTCS squelch function is in
use. (p. 110)
➥ “ S” appears with the “TSQL” or “DTCS” indicator
while the pocket beep function
(with CTCSS or DTCS) is
in use. (p. 111)
• While operating in DV mode;
➥ “ DSQL” appears while the call sign squelch function is
in use. (p. 110)
➥ “ CSQL” appears while the digital code squelch function
is in use. (p. 110)
• Dualwatch indication
• Single band indication
MemoName
μ
PRIO
PRIO EMR
DSQL
DSQL
DV
B
LOW
ATT
439 706
PSKIP
-DUP
-DUP
25
25
000
PS
PS
PRIO
PRIO
25
μ
000
000
88 100
DTCS
PS
PS
PRIO
PRIO
-DUP
-DUP
75
μ
000
000
439 706
q
!6 i e o
we r ty
!1
!8!1y !4
!2
!3
!7
q
!4
!5
!6
!7
u
t
!0
!6 w r e o
!8!1!2 !4
!7
i
!3
!0
i
o
!0
