Icom IC-92A - Optional HM-75 A; Remote Control Microphone

The optional HM-75A allows you to remotely select operat-
ing frequencies, memory channels, etc.
Remote control functions can be selected from 3 settings.
These can be selected with “MIC SIMPLE MODE” in set
mode.
(p. 90)
The HM-75A has a lock switch on the backside to prevent
accidental frequency changes, etc.
Be sure to turn power OFF when plugging the HM-75A to
the [DATA/MIC/SP] jack.
• NORM-1: (default)
• NORM-2:
• SIMPLE:
VFO mode cannot be selected via the microphone when
SIMPLE mode is selected.
SIMPLE mode can select only 3 channels and is useful
for group operations during touring, etc.
138
15
OPTIONS
New2001
■ Optional HM-75A REMOTE CONTROL MICROPHONE
[A] Selects band.
[B] Toggles VFO mode and memory mode.
[Y] Frequency or memory channel “UP”.
[Z] Frequency or memory channel “DOWN”.
[A] Toggles the monitor function.
[B] Toggles VFO mode and memory mode.
[Y] Frequency or memory channel “UP”.
[Z] Frequency or memory channel “DOWN”.
[A] Toggles the monitor function.
[B] Selects call channel C0.
[Y]
• Selects memory channel 000 in memory mode.
• Volume “UP” while operating the monitor function.
[Z]
• Selects memory channel 001 in memory mode.
• Volume “DOWN” while operating the monitor function.
❮MENU screen❯ ➪ ❮SET MODE❯ ➪ ❮MIC SIMPLE MODE❯
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
A
OFF ON
LOCK
B
PTT switch
Transmit LED
Earphone jack
Microphone
Speaker
†
[DIAL] ↔ [ ](2)/[ ](8) [ ](5) ↔ [ ](6)
