■ Memory bank setting
The IC-92A/92AD has a total of 26 banks (A to Z). Regular
memory channels, 000 to 799 (A band)/000 to 399 (B band),
are assigned to the desired bank for easy memory manage-
ment.
q Push and hold [S.MW](MR) for 1 sec. to enter select
memory write mode.
• 1 short and 1 long beep sound.
• “μ ” indicator blinks.
w Rotate [DIAL] to select the desired memory channel.
e Push [
](2) or [ ](8) to select “BANK.”
• Bank group and channel number is displayed if the selected
memory channel has already been previously assigned to a
bank.
r Push [ ](4) or [ ](6) several times to select the desired
bank group from “A” to “Z.”
t Rotate [DIAL] to select the bank channel number from
“00” to “99.”
• Only vacant bank channel numbers will be displayed.
y Push and hold [S.MW](MR) for 1 sec. to assign the chan-
nel to the bank.
• Return to the previous indication.
