7
D Low-speed data communication application
setting
Confi gure the low-speed data communication application as
follows.
• Port : The same COM port number as IC-92A/
92AD’s
• Baud rate : 38.4 kbps
(fi xed value)
• Data : 8 bit
• Parity : None
• Stop : 1 bit
• Flow control : Xon/Xoff
D Low-speed data communication operation
NOTE: Confi rm that in AUTO, the computer controls when
[PTT] is activated to send data and the user doesn’t have
to operate the radio.
q Set your own, station call signs, etc. as described in
“■ Digital voice mode operation”
(p. 38) and “■ Digital re-
peater operation”
(p. 41).
w Refer to the instructions of the low-speed data communi-
cation application.
e To transmit data
• With your voice audio, push and hold [PTT] to transmit while
sending data from the PC. Release [PTT] to receive.
• Under computer control, see Transmission condition setting at
right.
D Transmission condition setting
q Enter “DV DATA TX” in DV set mode. (p. 92)
w Rotate [DIAL]
†
to select “PTT” or “AUTO.”
PTT : The input data from [MIC/SP/DATA] are transmit-
ted when pushing [PTT].
(default)
AUTO : The input data from [MIC/SP/DATA] are transmit-
ted automatically when the data are input.
e Push [
](5) (or [ ](4)) to return to DV set mode, and push
[MENU/
] to return to frequency indication.
✔ For your information
While operating low-speed data communication via the inter-
net network from one zone to another zone, some packets
may be lost due to the network trouble (poor data throughput
performance). In such a case, the IC-92A/92AD displays an
“L” in the upper right corner on the display to indicate Packet
Loss has occured.
†
[DIAL] ↔ [ ](2)/[ ](8) [ ](5) ↔ [ ](6)
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
❮MENU screen❯ ➪ ❮DV SET MODE❯ ➪ ❮DV DATA T X ❯
(Push [MENU/
]) (Rotate [DIAL]
†
, then push [ ](5)
†
.)
