28
5
BASIC OPERATION
New2001
TV channel operation
TV channel operation is available only when TV channels
are programmed using the optional RS-91.
(p. 122) Also
available for A band operation only.
D TV channel receiving
q Push [CALL] several times to select TV channels.
TV” and channel number appear.
w Rotate [DIAL] to select the desired channel.
While pushing and holding [BAND], rotating [DIAL] selects the
all channels including skip channel.
D Skip channel setting
Unwanted channels can be skipped for rapid selection, etc.
q Push [CALL] several times to select TV channels.
“TV” and channel number appear.
w Rotate [DIAL] to select the channel to be skipped.
To clear the skip setting, rotate [DIAL] while pushing and hold-
ing [BAND] to select a skip channel.
e Push and hold [SKIP](5) for 1 sec. to toggle the skip set-
ting ON and OFF.
“SKIP” appears when the channel is set as skip channel.
D Automatic TV channel programming
TV channels can be programmed automatically.
q Push [CALL] several times
to select TV channels.
TV” and channel number ap-
pear.
w Push [SCAN](2) to start TV
channel programming.
The programming will automatically stop after scanning all
channels.
[DIAL]
CALL
RX
CS
C
TVTV
A
MemoNameMemoName
μ
PRIOPRIO WXWX EMREMR
DTCSDTCS
WFM
LOWLOW
ATTATT
10
CHCH
P SKIP
+DUP+DUP
2525
TV mode indication
Channel indication
[DIAL]
BAND
D
5
SKIP
CALL
RX
CS
C
TVTV
A
Mem oNameMemoName
µ
PRIOPRIO WXWXEMREM R
DTCSDTCS
WFMWFM
LOWLO W
AT TATT
12 ch
P SKIP
+DUP+DU P
2525
Appears
TV
TV
A
Mem oName
MemoName
µ
PRIO
PRIO
WX
WX
EMR
EM R
DTCS
DTCS
WFM
WFM
LOW
LO W
AT T
ATT
2 ch
P SKIP
+DUP
+D U P
25
25
