8 Applications
Linear
Linear LUT curve without effect
Negative
Predefined LUT, inverts the image
Glow1
Predefined LUT, false-color representation of the image
Glow2
Predefined LUT, false-color representation of the image
Astro1
Predefined LUT, false-color representation of the image
Rainbow1
Predefined LUT, false-color representation of the image
Map1
Predefined LUT, false-color representation of the image
Cold/Hot
Predefined LUT, false-color representation of the image
Sepic
Predefined LUT, uses sepia toning for coloring the image
Only red
Predefined LUT, shows only the red channel of the image
Only green
Predefined LUT, shows only the green channel of the
Only blue
Predefined LUT, shows only the blue channel of the
· Convert color to gray
When you are using a GigE uEye HE color camera, you can convert the color images to
monochrome in the camera before applying the LUT curve. This setting is recommended if you
want to use a LUT for false-color representation. The images are transferred in RGB format.
· Output
The diagram shows that part of the LUT curve that is selected in the Channel box. You can drag
and drop each knee point of the curve. To draw a smooth curve for the selected channel, left-click
on a blank space next to the curve.
· Mirror X/Y
These buttons allow mirroring the curve about the X and Y axes.
· Load/Save
Click Save to save the current LUT curve to a text file. With Load, you can load a saved LUT curve
from a file.
· Default
Click this button to reset all parameters to the model-specific defaults.
