16 Image Vault
®
PRO Command
Serial POS Data Hub Connection
If you have three or more POS data sources you will need one or up to two
IVQuad hubs. Each IVQuad hub device offers four data input ports. With two se-
rial ports on the DVR, this means up to 8 serial data sources may be connected to
one DVR. IVQuad data hubs are sold separately.
REGISTER
REGISTER
REGISTER
REGISTER
SERIAL
CABLE
JOURNAL
PRINTER
MULTI-SOURCE
PRINT SERVER
Multi-Device Print Server Serial Data Con-
nection
Though not as common, Image Vault also
supports multi-device serial print server ap-
plications. The wiring is the same as the direct
connection, but through software your DVR
can differentiate source channels.
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
+RS485
–RS485
GND
RS232
+RS485
–RS485
GND
RS232
+RS485
–RS485
GND
RS232
+RS485
–RS485
GND
RS232
+RS485
–RS485
GND
RX RS232
TX RS232
TO DVRFROM POS 1FROM POS 2FROM POS 3FROM POS 4
IVQ4 POS DATA HUB
SETUP POS 4 SETUP POS 3 SETUP POS 2 SETUP POS 1
BAUD:
19200
9600
4800
2400
1200
SWITCH #
1
OFF
ON
ON
ON
OFF
2
OFF
ON
ON
OFF
ON
3
ON
ON
OFF
ON
ON
7 DATA BITS
8 DATA BITS
1 STOP BITS
2 STOP BITS
RS232 IN
RS485 IN
SWITCH #
6
OFF
ON
7
ON
OFF
8
ON
OFF
PARITY:
NONE
EVEN
ODD
SWITCH #
IMAGE VAULT
Ph 888-462-4382 Fax 877-296-0038
www.image-vault.com
4
ON
OFF
ON
5
ON
ON
OFF
VIDEO SECURITY
D I G I T A L
PRO-COMMAND DVR
IVQ4
DATA SOURCES
REGISTER
REGISTER
SAFE
ATM
ACCESS
CONTROL
TO DVR
POS PORT
