IMS ROBOTICS MICRO S - Page 35

MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
35 of 113
10. Separate the cable entry completely from the
ferrule on one side
11. Push the ferrule to the side to access the
soldered joints
12. Push the heat shrink tubes to the side to expose
the individual solder joints
13. Separate soldered joints using the soldering
iron
