IMS ROBOTICS MICRO S - Page 40

MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
40 of 113
8. Apply Loctite 574 "orange" to the thread
9. Connect the sleeve firmly to the rear distributor
10. Apply Loctite 574 to the cleaned or new quick-
fit connectors
11. Screw all three quick-fit connectors into the
rear distributor
