10.3.2.1 REAL_xXx and REAL_xFx
Real numbers contain a decimal point.
The resolution (or decimal precision) of the real number displayed depends on
the format code.
The stored value is a floating-point number.
10.3.2.2 TIME
Time format is used for times with minutes and seconds.
Time parameters are displayed as MM:SS.
They are stored in memory as integer seconds.
10.3.2.3 ENCODE
Encode parameters have a defined list of acceptable values.
Usually two to five values are allowed.
As the user toggles through the list the encoded text is displayed on the screen.
The value stored is an integer.
10.3.2.4 INTEGER
Integers are 32-bit words.
Although they are stored as signed integers, all our current parameters have a
lower limit greater than or equal to 0.
10.3.2.5 LOCKCODE
The lock code parameter is displayed as "XXXX".
The value is stored as an integer.
Unlock code is 0.
REAL_5X3 XX.XXX
REAL_6F32 XXX.XXX or XXXX.XX
TIME MM:SS (Minutes:Seconds)
ENCODE Displays text from a Toggle list
INTEGER Whole number (no decimal point)
LOCKCODE XXXX
Table 10-1 Format code (continued)
Format Code Displays the value as
