3 - 43
IPN 074-505-P1E
IC6 Operating Manual
Do not remove the USB storage device from the IC6 while
a save or retrieve operation is taking place.
3.6.9 Lock and Access Codes
The IC6 has several forms of protection to prevent unauthorized changing of
parameters. Refer to the General setup section for a description of parameter and
Program lock codes and the File Access Code. In addition, a method of locking the
entire display is available through the remote communications. Lock codes are
entered on the General display. See Chapter 7, General Parameters.
HINT: To clear any of the locks, except the File Access Code, hold down the
CLEAR key on power up. This will clear all lock codes. HOWEVER, if no
lock codes are present, all parameters will be cleared.
3.6.10 Datalog
If enabled, Datalog automatically sends process information to the RS-232 port or
saves it to the USB storage device every time a source shutter closure occurs. an
end of deposit occurs, or following a Stop or Suspend. The information will be
saved under a filename on the USB storage device.
Datalog files saved to the USB storage device will be automatically named using
the process number and run number. The format of the filename is:
PXXRXXXX.IDL. If the USB storage device already contains a file with the same
filename as the new datalog information, the new datalog information will be
appended to the old file.
At each source shutter close, the datalog information will be appended to the file
(when saved to USB) until the end of the Process.
If two layers are co-deposited, the first layer to have a source shutter close will be
data-logged first.
Datalogging to RS-232 is active if the USB Datalog format is set to page or comma
in the Datalog page of the USB Storage screen. Datalogging the crystal frequency
data is an optional subset of the datalog string and is enabled by selecting Yes for
Datalog Xtal Info on the Comm page of the General screen. The Dlog Comma
protocol format is actually comma-and-quote delimited intended for file importation
into a spreadsheet program. When a spreadsheet program imports a file having the
comma delimited format, data groups that are strictly numbers become value
entries, data groups surrounded by quotes are stored as labels.
For the Dlog Page protocol format, only those sensors which are used in a
particular Material for a particular Layer will be datalogged.
