Inficon IC6

10 - 38
IPN 074-505-P1E
IC6 Operating Manual
10.4.24 Query Sensor Parameter
Command = QS <Command ID> <Sensor Number>
Command ID = <Byte> See Table 10-11.
Sensor Number = <Byte> Sensor number 1 - 8
Response = <Integer> | <Float>
Type of response depends on command ID, see Data Type column in Table 10-11.
10.4.25 Update Sensor Parameter
Command: = US <Command ID> <Sensor Number> <Parameter Value>
Command ID = <Byte> See Table 10-11
Sensor Number = <Byte> Sensor number 1 - 8
Parameter Value = <Integer> | <Float> Type of value depends on command ID,
see Data Type column in Table 10-11.
Response = None (Just header and trailer)
4
(0x04)
(Crucible)
Cruc
1/ 64/ 1 Integer Update not allowed if
active process is running
5
(0x05)
(Co-Deposition)
CoDep
0/ 1/ 0 Encode 0 = No 1 = Yes
When this layer is set to
yes the next layer will not
display.Gray font if next
layer is empty OR next
layer is set to Yes OR this
layer is the last layer.
Update not allowed if
active process is running
No update if the last
programmed layer OR if
the next layer's Co-Dep
parameter is set to Yes
6
(0x06)
(Ratio Control)
Ratio Cntrl
(%)
0/
999.9/
0
REAL_4X1 Gray Font when
Co-deposition is No
Table 10-10 Process layer parameters (continued)
QP
&
UP
Cmnd
ID
Name
(Units)
Range:
Low Limit/
High Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
