IC6 Operating Manual
12.6.4 Cross Talk Calibration SELECT display
After the RAMP down state the IC6 enters the SELECT display, from which the
user can accept or reject the calibration thickness values, as desired. If the values
are accepted they are stored on the Material’s Sensor page.
Figure 12-11 Crosstalk complete display
12.6.4.1 Function Key Selection Choices for
Cross Talk Calibration Select
Key Function Description
F3 ACCEPT Press this key to accept the Calibration Thickness
values and returns to the Cross Talk Calibration
SETUP display. The accepted Calibration Thickness
values are entered into page 3 of the Material Set-Up
display.
F4 REJECT Press this key to reject the Calibration Thickness
values and return to the Cross Talk Calibration
SETUP display.
