Inficon IC6

10 - 37
IPN 074-505-P1E
IC6 Operating Manual
10.4.22 Query Process Layer Parameter
Command: QP <Command ID> <Process Number><Layer Number>
Command ID = <Byte> See Table 10-10.
Process Number = <Byte> 1 - 50
Layer Number = <Byte> 1 - 200
Response = <Integer> | <Float>
Type of response depends on command ID, see Data Type column in Table 10-10.
10.4.23 Update Process Layer Parameter
Command = UP <Command ID> <Process Number><Layer Number>
<Parameter Value>
Command ID = <Byte> See Table 10-10.
Process Number = <Byte> 1 - 50
Layer Number = <Byte> 1 to 200
Parameter Value = <Integer> | <Float> Type of value depends on command ID,
see Data Type column in Table 10-10.
Response = None (Just header and trailer)
Table 10-10 Process layer parameters
QP
&
UP
Cmnd
ID
Name
(Units)
Range:
Low Limit/
High Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
1
(0x01)
Material 0/ 32/ 0 Integer 0 = Layer is not defined Update not allowed if
active process is running
2
(0x02)
(Final
Thickness)
Final Thick
(KÅ)
0.0/
999.999/
0.0
REAL_5F32
3
(0x03)
(Thickness Limit)
Thick Limit
(KÅ)
0.0/
999.999/
0.0
REAL_5F32
