Inficon IC6

10 - 41
IPN 074-505-P1E
IC6 Operating Manual
10.4.30 Status General
Command = SG <Command ID><Option>
Command ID = <Byte> See Description in Table 10-12.
Option = <Byte> |< Integer > | <32 Bit Word> | <48 Bit Word>
Response = <Byte>… <Byte> | <Integer>…<Integer
Table 10-12 Status general commands
SG
Comm
and ID
Description Option
Number
of bytes
in the
response
Data Returned Notes
0
(0x00)
N/A
1
(0x01)
Active process 4 <Integer>
2
(0x02)
Active layer(s) 1 to 7 <Byte>[<Byte>]
[<Byte>]…[<Byte>]
First byte is number of
active layers. The
following bytes are
which layer(s) is (are)
active
3
(0x03)
Output status 5 <Byte><Byte><Byte>
<Byte><Byte> Each bit
represents an output,
bit set means output
active.
MSB of first byte is
output 1.MSB of the
fifth byte is output 33.
4
(0x04)
Input status 4 <Byte><Byte><Byte>
<Byte> Each bit
represents an input. Bit
set means input active.
MSB of first byte is
input 1. MSB of the
fourth byte is input 25.
5
(0x05)
Logic statement
status
13 <Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte> Each bit
represents a logic
statement, bit set
means logic statement
is true.
MSB of first byte is logic
statement 1.MSB of the
thirteenth byte is logic
statement 97.
