Inficon IC6

10 - 20
IPN 074-505-P1E
IC6 Operating Manual
10.4.13 Update Logic Statement
Command = UL<Statement Number><Length of logic elements> <Set of
elements>
Statement Number = <Byte> 1 - 100
Length of logic elements = <Byte> number of bytes of the Logic element for each
statement, including the 0x03 (ETX) terminator.
Set of elements = See description in QL above.
Example: IF External Input 21 and External Input 2 and External Input 18 and
External Input 8
THEN Start Timer 1 and Extern Out On 10
Hex code for above including length and checksum:
1500554C01114115264102264112264108205101410A031A
Response = None (Just header and trailer)
Logic changes are not allowed while a process is running or if the IC6 is in a stop.
10.4.14 IC6 Event List
Events used in the Logic Statement IF section. Logic codes are used in the
remote communication query and update commands. The Logic codes start at
0x41 because there are formatting codes (for connectors, parentheses, etc.)
used in the logic statements that are ASCII codes below 0x41. See Table 10-7
.
Table 10-7 Event list
Events 1st
numeric
(1 Byte)
(XXX)
Min Max 2nd
numeric
(Integer)
(YYY)
Min Max Logic
Code
Logic
Code
Negated
Parenthesis
External Input Input # 1 28 0x41 0xBF
Pre-Deposit 0x42 0xBE
In Deposit 0x43 0xBD
Post-Deposit 0x44 0xBC
Non Deposit 0x45 0xBB
Ready 0x46 0xBA
Crucible Switch 0x47 0xB9
PreCond Rise 0x48 0xB8
PreCond Soak 0x49 0xB7
