Inficon IC6

10 - 45
IPN 074-505-P1E
IC6 Operating Manual
8
(0x08)
Power Source
Number
1 or 6 <Byte> Source number for the requested
layer.
9
(0x09)
Accumulated Layer
Time
4 or 24 <Integer> Seconds since "Ready"
10
(0x0a)
Deposit Average
Rate
4 or 24 <Float> KÅ Based on Averaging Time
parameter. Only available when in a
control state.
11
(0x0b)
Deposit Average
Power
4 or 24 <Float> % Based on Averaging Time
parameter. Only available when in a
control state.
12
(0x0c)
Raw Rate 4 or 24 <Float> Å/S
13
(0x0d)
One Minute
Averages for Rate
& Power
8 or 48 <Float><Float> Returns a 'No Data Error' if not
enough data to do a one minute
average of the rate or the power
14
(0x0e)
Rate Deviation /
power output trend
Varies
with # of
data
points
<Integer><Float>…
<Float>
Number of bytes in the response.
Average values from the operate
screen graph.
Format of each data point.
15
(0x0f)
State before
Suspend
1 or 6 <Byte> See encodes in section 3.5 on page
3-32. If not currently in Suspend, will
return "No Data Error"
16
(0x10)
Data Log 76 or 456 Multiple pieces of
information
See section 3.6.10 on page 3-43 for
order of data.
17
(0x11)
Data Log with Xtal
History
3,148
or
18,888
<Data Log + Crystal
data for 12 crystals in
8 sensors>.
See section 3.6.10 on page 3-43 for
order of data. Length of response =
76 bytes Data Log +
3072 bytes Xtal History
Xtal History = 32 bytes per crystal,
12 crystals in 8 sensors =
33*12*8=3072 bytes
Table 10-13 Status layer (continued)
SL
Command
ID
Description
Number
of bytes
in the
response
Data Returned Notes
