Inficon IC6

2 - 2
IPN 074-505-P1E
IC6 Operating Manual
Figure 2-1 Typical installation
Mounting Bracket
Coax Cable
(Routed with
Water Tubes)
Or,
Customer Supplied
Cajon Coupling
Brazing
Adapters
Water In
Water Out
XIU (Oscillator)
Instrument Chassis
Source
Source
Shutter
Pneumatic
Actuator
To
Source Controller
Source to Sensor
10" Minimum
Sensor
Shutter
Air, 80 PSI, 110 PSI Max.
To
Sensor
Shutter
IPN 750-420-G1
Shutter
Solenoid
Assembly
