14 General Information
iina74e 01.fm technical handbook(1408)
1.3.2.2 Electrical Data
1.3.2.3 Other Data
1.3.2.4 Ambient Conditions
1.4 Unpacking
Unpack the UL5000 immediately after delivery, even if it will be installed later on.
Examine the shipping container for any external damage. Completely remove the
packaging materials.
Check the UL5000 is complete (1.4.1 Supplied Equipment) and carefully examine
the UL5000 visually.
If any damage is discovered, report it immediately to the forwarding agent and
insurer. If the damaged part has to be replaced, please contact the orders
department.
Tipp Retain the packaging materials in the event of complaints about damage.
Tipp For unpacking please use the wedge which is part of the packaging.
Power supply, single phase (model dependent)
Part no. 550 - 500A 230 V 50 Hz
Part no. 550 - 501A 115 V 60 Hz
Power consumption 1200 VA
Type of protection IP20
Power cords (EU, USA, UK) 3 m
Valves solenoid
Dimensions (L × W × H) incl. handle in mm 1068 × 525 × 1083
Dimensions (L × W × H) incl. handle in inches 42 × 21 × 43
Weight in kg 140
Weight in lbs 308
Noise level dB (A) < 70
Noise level dB (A) 0.5 m distance 55.9
Audio alarm dB (A) 90
Contamination level (to IEC 60664-1) 2
Overvoltage category (to IEC 60664-1) II
For use within buildings
Permissible ambient temperature (during operation) +10 °C … +40 °C
Permissible storage temperature 0 °C … +60 °C
Max. rel. humidity 80% non condensing
Max. permissible height above sea level (during operation) 2000 m
